NewenGrid APower 500
High-capacity compact power station with 481Wh battery. Ideal for family camping, outdoor events, and emergency backup power.
OEM / ODM welcome
FOB / CIF wholesale pricing on request
Capacity481Wh
Rated Power500W
Battery TypeLithium-ion (NCM)
Cycles1000 cycles to 80%+ capacity
- 481Wh high-density lithium-ion battery
- 500W pure sine wave AC output
- Large capacity in a compact body
- Multi-port DC output for all your devices
- LCD display with real-time status
- Built-in 5W LED emergency light
Family Camping
Outdoor Events
Home Emergency
Road Trips
Global shipping & battery-certified packing
Samples available for testing
Overview
Product overview
High-capacity compact power station with 481Wh battery. Ideal for family camping, outdoor events, and emergency backup power.
At a glance
- 130000mAh / 481Wh — Battery Capacity
- Pure Sine Wave — 95-115Vac / 215-225Vac / 50Hz/60Hz ±3Hz
- AC 150W Max, ~3.5h — AC Wall Charging
- DC 12-24V/10A 100W Max, ~5h — Solar Charging (MPPT)
- 250×177×177mm (9.8×7.0×7.0in) · 4.8kg (10.6 lbs)
Customization
OEM / ODM available — your logo, packaging and manual.
Specifications
NewenGrid APower 500 — Key specifications
481Wh · 500W · Lithium-ion (NCM)
Battery Information
| Battery Type | Lithium-ion (NCM) |
|---|---|
| Battery Capacity | 130000mAh / 481Wh |
| Cycle Life | 1000 cycles to 80%+ capacity |
| Protection System | BMS: over-temp, under-temp, over-discharge, over-charge, overload, short-circuit, over-current |
AC Output
| Rated AC Output Power | 500W |
|---|---|
| AC Output Ports | ×2 |
| AC Output Voltage | 95-115Vac / 215-225Vac |
| AC Output Frequency | 50Hz/60Hz ±3Hz |
| Output Waveform | Pure Sine Wave |
DC & USB Output
| USB-A Output | ×3 QC3.0 18W Max |
|---|---|
| USB-C Output | ×1 PD 22.5W Max |
| Car Port (12V) | ×1 12V⎓10A Max |
| DC 5525 Output | ×1 12V⎓10A Max |
| Wireless Charging | 10W Max |
Charging Methods
| AC Wall Charging | AC 150W Max, ~3.5h |
|---|---|
| Car Charging | DC 12-15V/8A 100W Max, ~5h |
| Solar Charging (MPPT) | DC 12-24V/10A 100W Max, ~5h |
| Charge Temperature | 0°C ~ 45°C (32°F ~ 113°F) |
| Discharge Temperature | -10°C ~ 60°C (14°F ~ 140°F) |
Physical Specs
| Net Weight | 4.8kg (10.6 lbs) |
|---|---|
| Dimensions (L×W×H) | 250×177×177mm (9.8×7.0×7.0in) |
| Display | LCD Display |
| LED Light | 5W LED (Low/High/SOS/Flash) |
| Cooling System | Fan Cooling |
Applications
Where it works
Family Camping
Outdoor Events
Home Emergency
Road Trips
Related Products
Related models
APower Series
NewenGrid APower 400
345.1WhCapacity
500WRated Power
LiFePO4 (LFP)Battery Type
3000 cycles to 80%+ capacityCycles
APower Series
NewenGrid APower 1000
1024WhCapacity
1800WRated Power
LiFePO4 (LFP)Battery Type
3000 cycles to 80%+ capacityCycles
Product gallery
APower 500 — every angle, in plain photos
Series photography of the APower 500 platform: socket variants for each market, output bay, built-in lighting and export packaging. All photos are available as clean high-resolution files for your own listings.
Click any photo to enlarge. White-background studio shots and full-resolution originals are shared with every quotation.
Recharging
Three ways to recharge — flat to full in 3.5 hours
Charge times below are measured at the stated maximum input. The charging cables you need ship in the box.
AC wall socket
150 W max
≈ 3.5 h
0–100% from a mains socket with the included AC charging cable.
Solar panel
100 W max
≈ 5 h
12–24 V, 10 A solar input — a 100 W panel refills the 481 Wh battery in about 5 hours.
Car socket
100 W max
≈ 5 h
12–15 V, 8 A car charging — a full charge in about 5 hours of driving.
Charging times measured from 0–100% at 25 °C with the stated maximum input. Actual times vary with temperature and input voltage.
Runtime planning
How long will it run your appliances?
Estimated runtime by load, based on ≈ 409 Wh of usable capacity (85% depth of discharge).
| Appliance | Typical draw | Estimated runtime |
|---|---|---|
| LED camp light | 10 W | ≈ 40 h |
| Phone charging | 20 W | ≈ 20 h |
| Wi-Fi router | 15 W | ≈ 27 h |
| CPAP machine | 40 W | ≈ 10 h |
| Portable fridge (20 L) | 45 W | ≈ 9 h |
| LED TV (32") | 50 W | ≈ 8.1 h |
| Laptop | 60 W | ≈ 6.8 h |
| Ceiling fan | 60 W | ≈ 6.8 h |
| Mini projector | 80 W | ≈ 5.1 h |
Rule of thumb: runtime ≈ usable Wh ÷ load W. Keep continuous loads below 500 W; the inverter shuts down safely on overload.
Battery & safety
High-density NCM pack, tuned for portability
1000+
charge cycles to 80% capacity
High-energy-density NCM cells keep the pack at 4.8 kg — the lightest way to carry half a kilowatt-hour. Plan replacement cycles accordingly for daily heavy use.
- NCM (lithium-ion) cells — higher energy density than LiFePO4, so more capacity per kilo
- 7-way BMS: over-charge, over-discharge, over-current, overload, short-circuit, over-temperature and under-temperature protection
- Charge at 0–45 °C, discharge at −10–60 °C
- Pure sine wave inverter — safe for sensitive electronics, medical devices and tools
Traceability: every unit is serial-numbered and the cell batch is recorded, so quality claims can be traced back to the production lot. QC reports ship with every order.
Compliance
Compliance files available on request
Certificate documents for this model are not published here as images. They are requested from the partner factory when a buyer needs them — typically two to three business days — and we will confirm the current status for this specific model on request.
CE
Available on request — ask us for the current status for this model
FCC
Available on request — ask us for the current status for this model
RoHS
Available on request — ask us for the current status for this model
PSE
Available on request — ask us for the current status for this model
Full test reports for this model are available on request, and market-specific certificates are arranged per destination market. UN38.3 transport documentation is included in the shipping document set.
Applications
Four scenarios, one unit
Position it as family camping power, outdoor event supply, home emergency backup or road-trip power — the same SKU serves all four.
OEM / ODM
Your brand, our OEM platform
The APower 500 platform is available for private label. Start from a sample, scale to container orders with your own branding.
1
Logo & branding
Silkscreen or laser engraving on the shell, UI and boot screen.
2
Custom packaging
Colour box, master carton and inserts designed to your specification.
3
Plug & voltage
US, EU, UK or universal socket; 110 V and 220 V builds on the same platform.
4
Bundle kits
Pair with foldable solar panels or package multiple SKUs for your channel.
MOQ, lead time and tooling cost are confirmed with your quotation. Send your target market and volume — our export team replies within 12 business hours.
Packaging & logistics
Carton specification and what's in the box
Everything a freight forwarder needs to quote, and everything your customer receives.
| Product dimensions | 250 × 177 × 177 mm |
|---|---|
| Net weight | 4.8 kg |
| Carton size | Confirmed with quotation |
| Units per carton | 1 |
In the box
- 1 × APower 500 main unit
- 1 × AC charging cable (C8)
- 1 × Car charging cable
- 1 × User manual
Carton specification and container loading plan are provided with your quotation. Every unit is serial-numbered and QC-tested before dispatch.
FAQ
Questions buyers ask
Anything with a continuous draw under 500 W: phones, laptops, camera and drone batteries, LED lights, a portable fridge, a CPAP machine, a TV, a fan or small projectors. It is not sized for kettles, microwaves or power tools.
About 3.5 hours from a wall socket at the 150 W maximum AC input, about 5 hours from a 100 W solar panel, or about 5 hours from a car socket. All charging cables are included.
The APower 500 uses high-density NCM lithium-ion cells rated for 1000 cycles to 80% capacity. If your use case is heavy daily cycling, consider the LiFePO4-based APower 400 — it cycles three times as long.
Yes — a 10 W wireless charging pad is built into the top panel, so compatible phones charge without any cable.
CE, FCC, RoHS and PSE test reports are available on request, together with UN38.3 transport documentation for lithium shipments. Market-specific certificates are arranged per destination.
Yes. Logo printing, custom colour boxes and cartons, plug and voltage variants and bundle kits are all available. Send your target market and quantity for pricing, MOQ and lead time within 12 business hours.
