APower Series
NewenGrid APower 300
230.4WhCapacity
500WRated Power
LiFePO4 (LFP)Battery Type
3000 cycles to 80%+ capacityCycles
APower Series
2000Wh and above
APower Series
NewenGrid APower 5000 Trolley
Flagship 5.12kWh trolley-style energy storage system. 5000W output, MPPT solar input up to 6000W, APP remote monitoring — the ultimate whole-home backup solution.
OEM / ODM welcome
FOB / CIF wholesale pricing on request
Capacity5.12kWh
Rated Power5000W
Battery TypeLiFePO4 (LFP) 51.2V
Cycles3000+ cycles to 80%+ capacity
- 5.12kWh massive LiFePO4 battery
- 5000W rated / 6000W peak pure sine wave
- MPPT solar input up to 6000W
- 2-hour fast full charge
- Smart APP remote monitoring & control
- IP54 weatherproof rating
- Trolley + wheel design for mobility
Whole Home Backup
Commercial Use
Off-grid Solar System
Emergency Power Station
Global shipping & battery-certified packing
Samples available for testing
Overview
Product overview
Flagship 5.12kWh trolley-style energy storage system. 5000W output, MPPT solar input up to 6000W, APP remote monitoring — the ultimate whole-home backup solution.
At a glance
- 5120Wh (51.2V LiFePO4) — Battery Capacity
- Pure Sine Wave (THD<5%, Efficiency>91.5%) — 220/230/240Vac / 50Hz/60Hz
- AC 90-280Vac 10A, ~2h — AC Wall Charging
- PV 6000W Max, 500Vdc, MPPT 120-430Vdc, 80A — Solar Charging (MPPT)
- 498×336×620mm (19.6×13.2×24.4in) · ≈66kg (145.5 lbs)
Customization
OEM / ODM available — your logo, packaging and manual.
Specifications
NewenGrid APower 5000 Trolley — Key specifications
5.12kWh · 5000W · LiFePO4 (LFP) 51.2V
Battery Information
| Battery Type | LiFePO4 (LFP) 51.2V |
|---|---|
| Battery Capacity | 5120Wh (5.12kWh) |
| Cycle Life | 3000+ cycles to 80%+ capacity |
| Protection System | BMS: DC reverse polarity, AC short-circuit, leakage current, islanding, surge protection |
AC Output
| Rated AC Output Power | 5000W (6000W peak) |
|---|---|
| AC Output Ports | ×2 (240V) |
| AC Output Voltage | 220/230/240Vac |
| AC Output Frequency | 50Hz/60Hz |
| Output Waveform | Pure Sine Wave (THD<5%, Efficiency>91.5%) |
DC & USB Output
| USB-A Output | — |
|---|---|
| USB-C Output | — |
| Car Port (12V) | — |
| DC 5525 Output | — |
| Wireless Charging | — |
Charging Methods
| AC Wall Charging | AC 90-280Vac 10A, ~2h |
|---|---|
| Car Charging | — |
| Solar Charging (MPPT) | PV 6000W Max, 500Vdc, MPPT 120-430Vdc, 80A |
| Charge Temperature | 0°C ~ 45°C (32°F ~ 113°F) |
| Discharge Temperature | -10°C ~ 50°C (14°F ~ 122°F) |
Physical Specs
| Net Weight | ≈66kg (145.5 lbs) |
|---|---|
| Dimensions (L×W×H) | 498×336×620mm (19.6×13.2×24.4in) |
| Display | LED + APP Monitoring |
| LED Light | — |
| Cooling System | Intelligent Air Cooling |
Applications
Where it works
Whole Home Backup
Commercial Use
Off-grid Solar System
Emergency Power Station
Related Products
Related models
APower Series
NewenGrid APower 400
345.1WhCapacity
500WRated Power
LiFePO4 (LFP)Battery Type
3000 cycles to 80%+ capacityCycles
APower Series
NewenGrid APower 500
481WhCapacity
500WRated Power
Lithium-ion (NCM)Battery Type
1000 cycles to 80%+ capacityCycles
Product gallery
APower 5000 Trolley — the 5 kWh class, on wheels
Product image from the APower 5000 product manual. Higher-resolution originals, port and panel close-ups, and application photography are shared with your quotation on request.
Click the photo to enlarge. Full-resolution originals and additional angles are sent with every quotation.
Recharging
Recharge from the grid or the sun — flat to full in about 2 hours
Charge times below are measured at the stated maximum input. The charging cables you need ship in the box.
AC wall socket
AC 90–280 V, 10 A
≈ 2 h
0–100% from a mains socket with the included AC charging cable.
Solar / PV array
PV 6000 W max
full in one good sun day
Built-in MPPT accepts 120–430 Vdc PV arrays up to 6000 W — grid-tied-class solar input, far beyond portable units.
Charging times measured from 0–100% at 25 °C with the stated maximum input. Actual times vary with temperature and input voltage.
Runtime planning
How long will it run your appliances?
Estimated runtime by load, based on ≈ 4,352 Wh of usable capacity (85% depth of discharge).
| Appliance | Typical draw | Estimated runtime |
|---|---|---|
| Refrigerator (200 L) | 80 W | ≈ 54 h |
| LED lighting (whole home) | 50 W | ≈ 87 h |
| Wi-Fi router + laptop | 90 W | ≈ 48 h |
| LED TV (55") | 120 W | ≈ 36 h |
| Washing machine | 500 W | ≈ 8.7 h |
| Microwave | 1000 W | ≈ 4.4 h |
| Air conditioner (1 HP) | 750 W | ≈ 5.8 h |
| Circular saw | 1400 W | ≈ 3.1 h |
| Electric kettle | 2000 W | ≈ 2.2 h |
Rule of thumb: runtime ≈ usable Wh ÷ load W. Keep continuous loads below 5000 W; the 6000 W peak rating covers motor and compressor start-up surges.
Battery & safety
LiFePO4 chemistry at 51.2 V, sized for daily home cycling
3000+
charge cycles to 80% capacity
A 51.2 V LiFePO4 pack sized for daily home cycling — roughly 8–10 years of daily use.
- LiFePO4 (LFP) cells at 51.2 V — thermally stable chemistry with far lower thermal-runaway risk than NCM
- Inverter-grade protection: DC reverse polarity, AC short-circuit, leakage current, islanding and surge protection, plus DC switch and string detection
- Charge at 0–45 °C, discharge at −10–50 °C
- Pure sine wave inverter — safe for sensitive electronics, medical devices and tools
Traceability: every unit is serial-numbered and the cell batch is recorded, so quality claims can be traced back to the production lot. QC reports ship with every order.
Compliance
Compliance files available on request
Certificate documents for this model are not published here as images. They are requested from the partner factory when a buyer needs them — typically two to three business days — and we will confirm the current status for this specific model on request.
CE
Available on request — ask us for the current status for this model
FCC
Available on request — ask us for the current status for this model
RoHS
Available on request — ask us for the current status for this model
Full test reports for this model are available on request, and market-specific grid-tie or off-grid certificates are arranged per destination. UN38.3 transport documentation is included in the shipping document set.
Applications
Three scenarios, one unit
Position it as whole-home backup, off-grid solar storage or worksite and small-business power — the same SKU serves all three.
OEM / ODM
Your brand, our OEM platform
The APower 5000 platform is available for private label and system-integration projects. Start from a sample, scale to container orders with your own branding.
1
Logo & branding
Silkscreen or laser engraving on the shell, UI and boot screen.
2
Custom packaging
Colour box, master carton and inserts designed to your specification.
3
Plug & voltage
US, EU, UK or universal socket; 110 V and 220 V builds on the same platform.
4
Bundle kits
Pair with foldable solar panels or package multiple SKUs for your channel.
MOQ, lead time and tooling cost are confirmed with your quotation. Send your target market and volume — our export team replies within 12 business hours.
Packaging & logistics
Carton specification and what's in the box
Everything a freight forwarder needs to quote, and everything your customer receives.
| Product dimensions | 498 × 336 × 620 mm |
|---|---|
| Net weight | ≈ 66 kg |
| Carton size | Confirmed with quotation |
| Units per carton | 1 |
In the box
- 1 × APower 5000 main unit
- 1 × AC charging cable
- 1 × PV/solar input cable set
- 1 × User manual
Freight for this model is arranged on pallets; carton specification and container loading plan are provided with your quotation. Every unit is serial-numbered and QC-tested before dispatch.
FAQ
Questions buyers ask
The APower 5000 delivers 5000 W continuously and handles peaks up to 6000 W for a few seconds. Motor-driven loads such as pumps and air conditioners draw a surge at start-up, so keep continuous loads under 5000 W.
Two ways: from an AC wall circuit at up to 10 A (90–280 V, full in about 2 hours), or from a solar array — the built-in MPPT accepts 120–430 Vdc panels up to 6000 W, which is grid-tied-class solar input.
At 5.12 kWh, a small portable-style solar input would take days to refill the battery. The 6000 W MPPT input means a properly sized array recharges it in one good sun day, making true off-grid living practical.
No — the APower 5000 is designed around AC output and home-scale loads. It provides pure sine AC at 220/230/240 V (THD < 5%, efficiency above 91.5%) plus APP monitoring; small-device charging stays on your existing chargers.
CE, FCC and RoHS test reports are available on request, and market-specific certificates are arranged per destination. UN38.3 transport documentation is included in the shipping document set.
Yes — private label, custom enclosures and integration with your solar or inverter BOM are available. Send your target market and system design for pricing, MOQ and lead time within 12 business hours.
Ready to Power Your Business?
Get wholesale pricing, product samples, and dedicated support — our team responds within 12 hours.
- Global shipping & battery-certified packing
- OEM / ODM from 100 units
